Manufacturer DiscontinuedLimited Stock
Siemens
Siemens 6ES7 223-1BH22-0XA1 SIMATIC S7-200 EM 223 Combination Module 8DI/8DO DC
MPN: 6ES7 223-1BH22-0XA1
$350-600
Limited StockThe Siemens SIMATIC S7-200 EM 223 Combination Module is a versatile digital I/O expansion module that provides both inputs and outputs in a single unit. This model is part of the EM 223 series, designed to extend the capabilities of S7-200 PLCs by adding discrete I/O points. It i
| Digital Inputs | 8 x 24V DC |
|---|---|
| Digital Outputs | 8 x 24V DC Transistor |
| Input Current | 9 mA per input |
| Output Current | 0.75A per output |
| Isolation | 500V AC |
| Status Indicators | 16 x LED |
| Power Consumption | 3.5 W |
| Connector | 4 x 4-pin screw terminals |
| Dimensions | 137 x 80 x 60 mm |
CEULRoHS
- Contact us for detailed product features
- Industrial automation systems
