Limited Stock
Omron
C200H-AD001 Analog Input Unit
MPN: C200H-AD3
$200-350
Limited StockOmron C200H-AD3 C200H-AD001 Analog Input Unit — a reliable industrial plc for automation systems. Key specs: 12-bit (1 in 4096), +/- 0.3% at 25C. Features include 4-channel measurement, Voltage and current inputs. Suitable for temperature monitoring. Contact us for availability.
| Analog Inputs | 4 channels |
|---|---|
| Input Ranges | 0-10V (voltage), 0-20mA/4-20mA (current) |
| Resolution | 12-bit (1 in 4096) |
| Conversion Time | 2.5ms maximum (all channels) |
| Accuracy | +/- 0.3% at 25C |
| Input Impedance | 2M ohm (voltage), 250 ohm (current) |
| Signal Range Selection | Per channel via DIP |
| Average Function | Moving average available |
| Isolation | Photocoupler between input and PLC |
| Connectors | Detachable terminal block |
| Power Consumption | 5W |
| Dimensions | 34 x 130 x 110 mm |
| Weight | 0.4 kg |
CEUL
- 4-channel measurement
- Voltage and current inputs
- Per-channel range selection
- Moving average function
- 12-bit resolution
- Easy PLC integration
- Temperature monitoring
- Pressure measurement
- Flow rate monitoring
- Tank level sensing
- Load cell integration
- Process trending
