Mitsubishi
FX5U-80MT/ESS Transistor Output
FX5U-80MT/ESS
Request a Quote
Price Range: $700-1000 | Professional quotation within 24 hours
The MELSEC iQ-F FX5U-80MT/ESS is the flagship compact PLC in the FX5U series, featuring 40 digital inputs and 40 transistor source outputs. This high-performance controller offers AC power supply with 34ns instruction execution speed for maximum throughput. Built-in Ethernet and RS-485 ports enable seamless integration with HMIs and upper-level systems. The controller includes 2 analog inputs and 1 analog output, plus SD card support for program backup and data logging. High-speed counter functi...
| Power Supply | 100-240V AC |
|---|---|
| Digital Inputs | 40 x 24V DC (Sink/Source) |
| Digital Outputs | 40 x Transistor Source |
| Analog Inputs | 2 x 0-10V / 4-20mA |
| Analog Outputs | 1 x 0-10V |
| Program Memory | 64 KB steps |
| Execution Speed | 34 ns per LD instruction |
| Communication | 1 x Ethernet, 1 x RS-485 |
| High Speed Counter | Up to 8 channels (200 kHz) |
| Positioning | Up to 4 axes (200 kHz) |
| Expansion | Via extension cables |
| Dimensions | 285 x 90 x 86 mm |
| Weight | 1.4 kg |
| Operating Temp | 0 to 55°C |
| Certifications | CE, UL, cULus |
CEULcULus
- Maximum I/O capacity in FX5U
- Transistor outputs for high speed
- Built-in Ethernet connectivity
- Advanced positioning control
- SD card program storage
- Security and protection
- Large packaging machines
- High-speed conveyors
- Multiple axis positioning
- Industrial robots
- Semiconductor equipment
- Automated assembly
