Limited Stock
Mitsubishi
FX5U-64MT/ESS Transistor Source
FX5U-64MT/ESS
Request a Quote
Price Range: $680-950 | Professional quotation within 24 hours
The MELSEC iQ-F FX5U-64MT/ESS is a high-performance compact PLC with 32 digital inputs and 32 transistor source outputs. This flagship model in the FX5U series offers maximum I/O capacity with 64KB steps program memory and 34ns execution speed. Built-in Ethernet and RS-485 provide versatile connectivity. The controller includes analog functionality and SD card support for program backup and data logging. High-speed positioning up to 4 axes makes this PLC ideal for advanced motion applications....
| Power Supply | 100-240V AC |
|---|---|
| Digital Inputs | 32 x 24V DC |
| Digital Outputs | 32 x Transistor Source |
| Analog Inputs | 2 ch |
| Analog Outputs | 1 ch |
| Program Memory | 64 KB steps |
| Execution Speed | 34 ns |
| Communication | Ethernet, RS-485 |
| High Speed Counter | 8 ch (200 kHz) |
| Positioning | 4 axes (200 kHz) |
| Dimensions | 220 x 90 x 86 mm |
| Operating Temp | 0 to 55°C |
| Certifications | CE, UL |
CEUL
- 64 I/O capacity
- Source outputs
- Motion control
- High-speed counting
- High-speed packaging
- Multiple axis positioning
- Robotics
- CNC auxiliary
- Assembly automation
