Mitsubishi
FX5U-32MT/ES Transistor Output
FX5U-32MT/ES
Request a Quote
Price Range: $420-620 | Professional quotation within 24 hours
The MELSEC iQ-F FX5U-32MT/ES is a compact PLC with AC power supply and 16 digital inputs plus 16 transistor sink outputs. This high-performance controller features 34ns instruction execution speed and extensive built-in functionality. Built-in Ethernet and RS-485 ports provide versatile communication options. The controller includes 2 analog inputs and 1 analog output, plus SD card support. High-speed counter functions up to 200kHz and positioning control for up to 4 axes make this PLC suitable ...
| Power Supply | 100-240V AC |
|---|---|
| Digital Inputs | 16 x 24V DC |
| Digital Outputs | 16 x Transistor Sink |
| Analog Inputs | 2 ch |
| Analog Outputs | 1 ch |
| Program Memory | 64 KB steps |
| Execution Speed | 34 ns |
| Communication | Ethernet, RS-485 |
| High Speed Counter | 6 ch (200 kHz) |
| Positioning | 4 axes (200 kHz) |
| Dimensions | 150 x 90 x 86 mm |
| Operating Temp | 0 to 55°C |
| Certifications | CE, UL |
CEUL
- Transistor outputs
- 34ns speed
- Built-in Ethernet
- Motion control
- Packaging
- Conveyors
- High-speed counting
- Positioning
- Textile machinery
