Mitsubishi
FX1N-40MR Base Unit
FX1N-40MR-ES/UL
Request a Quote
Price Range: $250-400 | Professional quotation within 24 hours
The MELSEC-F FX1N-40MR is a 40-point base unit with relay outputs, offering an economical solution for applications requiring switching of AC loads or higher current ratings than solid-state outputs can provide. This PLC unit provides 24 digital inputs and 16 relay outputs, with each output capable of handling up to 2A at 250V AC or 2A at 30V DC, making it suitable for direct connection to contactors, solenoid valves, and indicator lamps without external relay interfaces. The relay output config...
| Digital Inputs | 24 x 24V DC (Sink/Source) |
|---|---|
| Digital Outputs | 16 x Relay (2A, 250V AC / 30V DC) |
| Relay Life | 100,000 operations (resistive load) |
| Power Supply | 100-240V AC, 50/60Hz |
| Program Memory | 8K steps EEPROM |
| Data Memory | 8,000 registers |
| Processing Speed | 0.55-0.7us per basic instruction |
| Timer Capacity | 256 timers |
| Counter Capacity | 256 counters |
| Expansion Modules | Up to 2 modules |
| Communication | RS-422 (built-in) |
| Dimensions | 150 x 90 x 87 mm |
| Weight | 1.0 kg |
| Power Consumption | 30VA |
CEULcULus
- High-current relay outputs
- AC/DC load compatibility
- Galvanic isolation
- EEPROM program storage
- Compact footprint
- Easy load wiring
- AC motor starters
- Solenoid valve control
- Indicator lamp drives
- Contactor switching
- Heating element control
- Simple ON/OFF control systems
