Limited Stock
KEYENCE
KEYENCE LR-T Series Laser Sensor
MPN: LR-TB5002
$400-700
Limited StockKEYENCE LR-TB5002 KEYENCE LR-T Series Laser Sensor — a reliable industrial sensor for automation systems. Features include TOF technology immune to color, IP67 metal housing. Suitable for long-range detection. Contact us for availability. Fast global shipping from ZZSL Automation
| Detection Range | 60 to 5000mm |
|---|---|
| Detection Method | Time of Flight (TOF) |
| Light Source | 660nm red laser (Class 2) |
| Output Type | NPN open collector |
| Response Time | 1.5ms / 3ms / 5ms / 10ms / 25ms / 50ms / 100ms selectable |
| Power Supply | 20-30V DC |
| Current Consumption | 40mA or less |
| Output Rating | 100mA (30V DC) |
| Housing Material | Metal (zinc die-cast) |
| Protection | IP67 |
| Operating Temp | -10 to +50C |
| Storage Temp | -25 to +70C |
| Dimensions | 31 x 22 x 77.5 mm |
| Weight | 120g |
| Cable | 4-wire, 2m |
CEULcULus
- TOF technology immune to color
- IP67 metal housing
- Selectable response times
- Easy teach configuration
- NPN output
- Background suppression
- Long-range detection
- Level detection tanks/silos
- Presence detection doors/barriers
- Object detection conveyors
- Height measurement
- Automotive assembly
