SMC ZSE20 Digital Pressure Switch

Name: SMC ZSE20
Brand: SMC
SKU: smc-zse20
Availability: LimitedAvailability

ZSE20

Get a Free Quote

Why Choose ZZSL?

Global Stock

Warehouses in China, Germany & USA for fast delivery worldwide

100% Quality

Every part verified for authenticity with our quality guarantee

48hr Shipping

Express options available for urgent requirements

Expert Support

Technical team available for product selection & troubleshooting

Product Description

The SMC ZSE20F is a digital pressure switch with 3-color display offering compound vacuum to positive pressure measurement from -100 to 100 kPa, designed for precise monitoring and control of pneumatic system pressure. This pressure switch features a large 3-color LCD display that provides clear visual indication of pressure status, with green indicating normal range, red for alarm conditions, and orange for warning states. The ZSE20F offers two PNP transistor outputs with selectable output modes including hysteresis, window comparator, and output 2 as alarm output with memory function. The 0.5% F.S. accuracy ensures reliable measurement for quality-critical applications, while the compact 30mm width allows installation in space-constrained locations.

Technical Specifications

Pressure Range -100 to +100 kPa

Proof Pressure 500 kPa

Accuracy 0.5% F.S.

Display 3-color LCD (green/red/orange)

Response Time 1.5ms or less

Output 2 x PNP open collector

Output Mode Hysteresis, Window comparator, Alarm

Set Mode External input or keypad

Power Supply 12-24V DC

Current Consumption 40mA or less

Connection G1/8 pneumatic, M12 electrical

Protection IP40

Dimensions 30 x 30 x 48 mm

Weight 0.08 kg

Applications

Vacuum monitoring Pressure switching Leak detection Clamping control Pick and place Pneumatic automation

Key Features

3-color status display Compound vacuum/positive Dual PNP outputs Memory function Compact 30mm width Quick response

Certifications

CE UL
