C200HX-CPU85-ZE High-Performance PLC

Name: Omron C200HX-CPU85-ZE
Brand: Omron
SKU: omron-c200hx-cpu85
Availability: LimitedAvailability

C200HX-CPU85-ZE

Get a Free Quote

Why Choose ZZSL?

Global Stock

Warehouses in China, Germany & USA for fast delivery worldwide

100% Quality

Every part verified for authenticity with our quality guarantee

48hr Shipping

Express options available for urgent requirements

Expert Support

Technical team available for product selection & troubleshooting

Product Description

The Omron C200HX-CPU85-ZE is the flagship model in the C200H series, offering the highest I/O capacity and program memory for demanding automation applications requiring up to 480 I/O points. This high-performance PLC CPU supports extensive instruction sets including PID control, floating-point arithmetic, and data processing functions suitable for complex process automation. The CPU85 variant offers the largest program memory at 7.2K words, enabling sophisticated control algorithms and extensive data handling capabilities. Multiple communication ports including RS-232C and RS-485 allow connection to HMI terminals, barcode readers, and host systems without additional options. Officially discontinued in March 2017, this CPU remains popular for maintaining existing C200H installations.

Technical Specifications

I/o Capacity 480 points maximum

Program Memory 7.2K words

Data Memory 6K words

Instruction Time 0.375us (basic)

Rs232c Port 1 port (host link, NT link, data link)

Rs485 Port 1 port (1:N link, NT link)

Special Units Up to 10 units

Timer/counter 512/512

I/o Bits 8192 bits

Programming Ladder diagram, Mnemonic

Software SYSWIN, CX-Programmer

Power Supply Built-in 24V DC output

Dimensions 130 x 110 x 65 mm

Weight 0.7 kg

Operating Temp 0 to 55C

Applications

Large process control Batch process management Industrial furnace control Multi-station assembly Quality inspection systems Centralized control systems
