Omron

C200H-NC111 Position Control Unit

Name: Omron C200H-NC111
Brand: Omron
SKU: omron-c200h-nc111
Availability: LimitedAvailability

C200H-NC111

Get a Free Quote

Why Choose ZZSL?

Global Stock

Warehouses in China, Germany & USA for fast delivery worldwide

100% Quality

Every part verified for authenticity with our quality guarantee

48hr Shipping

Express options available for urgent requirements

Expert Support

Technical team available for product selection & troubleshooting

Product Description

The Omron C200H-NC111 is a single-axis position control unit designed to add high-performance motion control capabilities to C200H, C200HS, and C200HX/HG/HE PLC systems. This unit generates high-speed pulse trains for controlling stepper drives or servo drives with pulse/direction inputs, enabling precise positioning control for packaging, assembly, and material handling applications. The NC111 supports both absolute and incremental positioning modes, with backlash compensation and electronic gear functions for complex motion profiles. The unit provides 250,000 pulses per second maximum output frequency, adequate for most stepper and microstepping applications.

Technical Specifications

Controlled Axes 1

Position Range +/-8,388,607 pulses

Max Pulse Rate 250 kpps (pulse/direction)

Positioning Modes Absolute, Incremental, Jog, Home search

Servo Functions Servo ready, Servo on, Origin proximity, Z-phase

Electronic Gear 1/1000 to 1000/1

Backlash Compensation 0-9999 pulses

Acceleration/deceleration Linear, S-curve

Error Check Position deviation, Overtravel

Interface Pulse train output (line driver)

Connectors 25-pin D-sub

Power Consumption 5W

Dimensions 34 x 130 x 110 mm

Weight 0.3 kg

Applications

Precision linear stages Screwdriver positioning Labeling machines Cutting systems XY tables Conveyor positioning

Key Features

Single-axis point-to-point High-speed pulse output Absolute/incremental positioning Electronic gear mode Backlash compensation Home search functions

Certifications

CE UL
