Omron

C200H-AD001 Analog Input Unit

Name: Omron C200H-AD001
Brand: Omron
SKU: omron-c200h-ad001
Availability: LimitedAvailability

C200H-AD001

Get a Free Quote

Why Choose ZZSL?

Global Stock

Warehouses in China, Germany & USA for fast delivery worldwide

100% Quality

Every part verified for authenticity with our quality guarantee

48hr Shipping

Express options available for urgent requirements

Expert Support

Technical team available for product selection & troubleshooting

Product Description

The Omron C200H-AD001 is a 4-channel analog input unit providing interface between analog sensors and transducers and C200H series PLC systems. This unit accepts voltage signals (0-10V) and current signals (0-20mA or 4-20mA) from process instrumentation, enabling PLC-based monitoring and control of analog processes. The 12-bit resolution provides 1 in 4096 measurement accuracy, sufficient for most process monitoring and data acquisition applications. Each channel can be independently configured for voltage or current input, with individual signal type selection via DIP switches on the unit. The maximum conversion time of 2.5ms ensures responsive signal tracking for closed-loop control applications.

Technical Specifications

Analog Inputs 4 channels

Input Ranges 0-10V (voltage), 0-20mA/4-20mA (current)

Resolution 12-bit (1 in 4096)

Conversion Time 2.5ms maximum (all channels)

Accuracy +/- 0.3% at 25C

Input Impedance 2M ohm (voltage), 250 ohm (current)

Signal Range Selection Per channel via DIP

Average Function Moving average available

Isolation Photocoupler between input and PLC

Connectors Detachable terminal block

Power Consumption 5W

Dimensions 34 x 130 x 110 mm

Weight 0.4 kg

Applications

Temperature monitoring Pressure measurement Flow rate monitoring Tank level sensing Load cell integration Process trending

Key Features

4-channel measurement Voltage and current inputs Per-channel range selection Moving average function 12-bit resolution Easy PLC integration

Certifications

CE UL
