Mitsubishi

FX1N-40MR Base Unit

Name: Mitsubishi FX1N-40MR-ES/UL
Brand: Mitsubishi
SKU: mitsubishi-fx1n-40mr
Availability: InStock

FX1N-40MR-ES/UL

Get a Free Quote

Why Choose ZZSL?

Global Stock

Warehouses in China, Germany & USA for fast delivery worldwide

100% Quality

Every part verified for authenticity with our quality guarantee

48hr Shipping

Express options available for urgent requirements

Expert Support

Technical team available for product selection & troubleshooting

Product Description

The MELSEC-F FX1N-40MR is a 40-point base unit with relay outputs, offering an economical solution for applications requiring switching of AC loads or higher current ratings than solid-state outputs can provide. This PLC unit provides 24 digital inputs and 16 relay outputs, with each output capable of handling up to 2A at 250V AC or 2A at 30V DC, making it suitable for direct connection to contactors, solenoid valves, and indicator lamps without external relay interfaces. The relay output configuration provides galvanic isolation between the PLC electronics and the load circuit, protecting against voltage transients and allowing switching of heterogeneous voltage systems.

Technical Specifications

Digital Inputs 24 x 24V DC (Sink/Source)

Digital Outputs 16 x Relay (2A, 250V AC / 30V DC)

Relay Life 100,000 operations (resistive load)

Power Supply 100-240V AC, 50/60Hz

Program Memory 8K steps EEPROM

Data Memory 8,000 registers

Processing Speed 0.55-0.7us per basic instruction

Timer Capacity 256 timers

Counter Capacity 256 counters

Expansion Modules Up to 2 modules

Communication RS-422 (built-in)

Dimensions 150 x 90 x 87 mm

Weight 1.0 kg

Power Consumption 30VA

Applications

AC motor starters Solenoid valve control Indicator lamp drives Contactor switching Heating element control Simple ON/OFF control systems

Key Features

High-current relay outputs AC/DC load compatibility Galvanic isolation EEPROM program storage Compact footprint Easy load wiring

Certifications

CE UL cULus
