Allen-Bradley

MicroLogix 1000 PLC 16 I/O

Name: Allen-Bradley 1761-L16BBA
Brand: Allen-Bradley
SKU: allen-bradley-micrologix-1000
Availability: LimitedAvailability

1761-L16BBA

Get a Free Quote

Why Choose ZZSL?

Global Stock

Warehouses in China, Germany & USA for fast delivery worldwide

100% Quality

Every part verified for authenticity with our quality guarantee

48hr Shipping

Express options available for urgent requirements

Expert Support

Technical team available for product selection & troubleshooting

Product Description

The Allen-Bradley MicroLogix 1000 1761-L16BBA is a compact PLC offering 10 inputs and 6 relay outputs, designed as an entry-level controller for simple automation applications requiring reliable and cost-effective control. This controller features 1KB of memory for ladder logic program storage, with the fixed I/O configuration eliminating the need for expansion modules in many simple applications. The built-in RS-232 communication port supports DF1 half-duplex protocol for connection to HMI terminals, programming software, or other serial devices. The MicroLogix 1000 supports the basic instruction set including timers, counters, and math operations, providing sufficient capability for straightforward ON/OFF control applications.

Technical Specifications

Digital Inputs 10 x 24V DC (Sink/Source)

Digital Outputs 6 x Relay (2A, 240V AC)

Program Memory 1KB

Data Memory 384 words

Timer/counter 20 each

I/o Status Fixed configuration

Communication RS-232 (DF1 half-duplex)

Power Supply 24V DC

Execution Time 0.5ms/k typical

Battery Backup Not available (capacitor)

Dimensions 130 x 80 x 40 mm

Weight 0.3 kg

Operating Temp 0 to 55C

Certifications UL, CSA, CE

Applications

Simple conveyor control Pump stations HVAC units Small packaging Lighting control OEM machinery

Key Features

Compact fixed I/O Built-in RS-232 Low cost solution RSLogix 500 programming Relay outputs for AC DIN rail mount

Certifications

CE UL cULus CSA
