Siemens
SIMATIC S7-200 EM 232 Analog Output Module
6ES7 232-0HB22-0XA0
Get a Free Quote
Contact us for best pricing, quantity discounts, and availability
Category
Analog I/O Module
Availability
Limited Stock
Status
Active
Recommended Replacement
Contact us for information
Why Choose ZZSL?
Global Stock
Warehouses in China, Germany & USA for fast delivery worldwide
100% Quality
Every part verified for authenticity with our quality guarantee
48hr Shipping
Express options available for urgent requirements
Expert Support
Technical team available for product selection & troubleshooting
Product Description
SIMATIC S7-200 EM 232 is an analog output expansion module with 2 voltage or current outputs. This module generates analog control signals for variable frequency drives, valve positioners, and chart recorders. Discontinued in October 2017, the EM 232 remains essential for retrofitting analog control loops in older facilities. Features 12-bit resolution with short-circuit protection on voltage outputs.
Technical Specifications
Analog Outputs
2
Output Type
Voltage or Current (switches)
Voltage Ranges
±10V, 0-10V
Current Ranges
0-20mA, 4-20mA
Resolution
12-bit D/A converter
Output Load
5kΩ min (voltage), 500Ω max (current)
Accuracy
±1% of full scale
Protection
Short-circuit (voltage), overcurrent (current)
Power Consumption
3 W
Dimensions
46 x 80 x 62 mm
